Specifications
Light source:
• Top white light;
• Side white light;
• Transmission white light;
• Top infrared light;
• Side infrared light;
• Transmission infrared light;
• Infrared cross-light (850nm/940nm) IR+Blue 470nm;
• Dual tube UV light (UV254nm UV365nm);
• Infrared laser light.
Imager sensor:
• Full screen 5M pixel image sensor;
• Regional 520 linear HD image sensors;
• Equipped with no distortion HD Infrared lens and optical filter auto switching system.
Magnification:
• Whole screen 1:1 with digital magnification 1: (8-100);
• Partial screen (1:35).
Magnification lens:
• 100mmx50mm;
• UVlight filter glass dual light magnification lens;
• 3.5x for main lens and 5x for doubling lens.
Power supply: 100-240V AC.
Net weight: 1.45kg.
Device Size: 280L 175W 265H (mm).
